Advanced Vehicle Remote Fuel Consumption Monitoring System
SA-OS uses high-frequency ultrasonic detection technology to measure the height of the non-contact liquid surface of fuel and liquid substances. Compared with the traditional liquid level detection equipment, the ultrasonic liquid level has high measurement accuracy and is easy to use. It can be mounted (does not destroy the container structure) and connected to the networked equipment to achieve remote liquid level monitoring. The ultrasonic oil level sensor is specialized for the installation and algorithm optimization of the vehicle oil volume monitoring, which can adapt to the complex road conditions and the real-time oil volume monitoring for the vehicles with a special fuel tank and can also output stable data to the tank liquid level of the dangerous goods transport vehicles.
Product characteristics
lWaterproof, lightweight structure design; do not open hole installation.
lUnique double bolted bolt fixed bracket, simple installation, firmly fixed, easy to remove;
lDC 5V and 9~36V power supply, suitable for a variety of positioning host and vehicles;
lRS232 / RS485 / 4-20 mA A current / 0-5V voltage analog quantity of four communication interfaces.
lSuper signal strength, suitable to fuel tanks and tanks of different materials;
lBuilt-in anti-interference structure and circuit, intelligent algorithm filtering, high and stable output;
lBuilt-in high-precision calculation model, millimeter-level measurement resolution;
Scope of Application
lVehicle remote fuel consumption monitoring;
lBody fluid level monitoring of hazardous chemical transport vehicles;
lRemote monitoring of fuel consumption of construction machinery;
lWater level monitoring of the sprinkler water tank;
lMonitoring of fuel consumption of the marine fuel tank;
lLiquid level measurement of liquid storage tank (single level);
lFilling of liquid gas measurement.
Parameter | Specification description | Unit | Remarks | |
Input voltage | DC5 | DC9～36 | V | Two voltage versions |
Working current | ≤20 | ≤30 | mA |
|
Anti-hazard classification | Benan Exia II CT6 |
|
| |
Measuring range | 50～1000/2000 | mm | (1) | |
Measurement, accuracy | ≤0.5% FS |
| (1) | |
Resolution ratio | 0.1 | mm |
| |
Measuring Angle | 0～5 |
| (2) | |
Thickness of the test | 0.6～5.0 | mm | Blind area of 5 cm (3) | |
5.0～10.0 | mm | Blind area of 10 cm (3) | ||
≥10.0 | mm | (3) | ||
Communication interface | RS232/RS485 |
| (4) | |
Communication rate | 9600 | bit/S | Porter rate adjustable | |
Line order definition | Black-ground line; Red-positive pole; Yellow-TX/B; Green-RX/A | |||
Remarks:
1. At normal temperature and 1 standard atmosphere of pressure, the default measured liquid is 0 # diesel. The range can be modified; the detection range is greater than 100 cm or other liquid mediums. Please indicate the range and liquid corresponding to the sound shipment.
2. Container wall thickness of 2 mm, steel quality, content of ~10~100 cm diesel oil, transform the container tilt Angle test;
3. Blind area value is determined by the material and thickness of the container. The blind area value of a ~5~10 mm wall thickness needs to be reduced, or the blind area value of 10 mm wall thickness. Please provide material and accurate wall thickness, and reset the minimum blind area value for shipment.
4. The long-term stock is the RS232 and RS485 interface. The voltage and current analog output should be booked in advance. The transmission distance of RS232 is less than 10m, and RS485 over 10m communication distance should be selected
